$665.99
10G Cloud Gateway with 200+ UniFi device / 2,000+ client support, 5 Gbps IPS routing, and redundant NVR storage.
- Model: UDM-PRO-MAX
- Authorized Ubiquiti dealer — full US warranty
- Professional installation available across Texas
- Questions? Call or text (713) 824-1035
Available on backorder
Description
Ubiquiti UniFi Dream Machine Pro Max (UDM-PRO-MAX) — Authorized Ubiquiti Dealer in Texas
10G Cloud Gateway with 200+ UniFi device / 2,000+ client support, 5 Gbps IPS routing, and redundant NVR storage.
Texas Technology Group has supported businesses in Round Rock and across Texas since 2002. We recommend the UniFi Dream Machine Pro Max for secure routing, firewall and VPN for a growing office, and for multi-site networks that need centralized management. Buy it on its own, or let our team handle design, installation, configuration and ongoing management as part of a TTG managed network.
Key Features
- Enhanced computing power and memory for 2x the UniFi device and client capacity of Dream Machine Pro/SE
- Includes full UniFi application suite for device management
- 5 Gbps routing with IDS/IPS
- (1) 10G SFP+*, (8) GbE RJ45 LAN ports
- (1) 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports
- (2) 3.5" NVR HDD bays with RAID data protection
- Built-in 128 GB SSD for NVR detection recordings
- UniFi Power Backup ready
- 1.3" touchscreen
- *Pair with an official SFP+ Module or SFP+ to RJ45 Adapter for the best experience.
UniFi Dream Machine Pro Max (UDM-PRO-MAX) Specifications
| IDS/IPS | 5 Gbps |
|---|---|
| Max. Client Count | 2,000 |
| IDS/IPS Throughput | 5 Gbps |
| Overview | |
| Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
| Managed UniFi Devices | 200+ |
| Managed Cameras | (50) HD (25) 2K (15) 4K |
| Managed Access Hubs | 150 |
| Simultaneous Users Connected | 2,000+ |
| Max. WAN Port Count | 8 |
| Default WAN Ports | (1) 10G SFP+ (1) 2.5 GbE RJ45 |
| 1 GbE RJ45 | 8 (1G/100M/10M) |
| 2.5 GbE RJ45 | 1 (2.5G/1G/100M/10M) |
| 10G SFP+ | 2 (10G/1G) |
| IDS/IPS Throughput | 5 Gbps |
| Form Factor | Rack mount (1U) |
| Redundancy | Shadow Mode (VRRP) Gateway Failover DC Power Backup (Enable DC power backup using UniFi RPS) |
| Security | |
| IDS/IPS Signatures | 55,000+ with CyberSecure |
| Networking | |
| MAC Address Table Size | 4,000 |
| Hardware | |
| NVR Storage | (2) 3.5" NVR HDD bays Built-in 128 GB SSD for Faster Experience |
| Max. Power Consumption | 60W |
| Power Method | (1) Universal AC input, 100–240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 8.7A |
| Power Supply | AC/DC, internal, 100W |
| Supported Voltage Range | 100–240V AC |
| Heat Dissipation | 205 BTU/hr |
| Processor | Quad-core ARM® Cortex®-A57 at 2.0 GHz |
| System Memory | 8 GB |
| On-board Storage | 32 GB eMMC 128 GB SSD (Integrated) |
| Weight | 4.7 kg (10.4 lb) |
| Enclosure Material | Aluminium CNC, SGCC steel |
| Mount Material | SGCC steel |
| LCM Display | 1.3" touchscreen |
| Management | Ethernet Bluetooth |
| Button | (1) Factory reset |
| ESD/EMP Protection | Air: ± 15kV, contact: ± 8kV |
| Ambient Operating Temperature | -10 to 40° C (14 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC, Anatel: 06369-24-08356, SRRC |
Why Buy Ubiquiti from Texas Technology Group?
- Authorized Ubiquiti reseller — genuine products with full US manufacturer warranty.
- Texas-based experts — Houston headquarters serving Corpus Christi, Dallas–Fort Worth, Austin, San Antonio and statewide.
- Design, install & manage — site surveys, cabling, configuration and ongoing managed IT support.
- Business & volume pricing — quotes for multi-site and project deployments.
Frequently Asked Questions
Can TTG install the UniFi Dream Machine Pro Max at my business in Round Rock?
Yes. Our technicians install and configure Ubiquiti equipment throughout Texas. Call or text (713) 824-1035 to schedule.
Is the UDM-PRO-MAX covered by warranty?
Yes. Texas Technology Group is an authorized Ubiquiti dealer, so every product ships new with the standard Ubiquiti manufacturer warranty. UI Care extended coverage is available for many models.
Do you offer project or volume pricing?
Yes — contact us at (713) 824-1035 for multi-unit, multi-site or full-deployment quotes.
Browse more: Large Scale Gateways.
Additional information
| Weight | 13.05 lbs |
|---|
