$702.99
A 48-port, Layer 3 Etherlighting™ switch with 2.5 GbE.
- Model: USW-PRO-MAX-48
- Authorized Ubiquiti dealer — full US warranty
- Professional installation available across Texas
- Questions? Call or text (713) 824-1035
Available on backorder
Description
Ubiquiti UniFi Switch Pro Max 48 (USW-PRO-MAX-48) — Authorized Ubiquiti Dealer in Texas
A 48-port, Layer 3 Etherlighting™ switch with 2.5 GbE.
Texas Technology Group has supported businesses in Pearland and across Texas since 2002. We recommend the UniFi Switch Pro Max 48 for segmenting guest, staff and device traffic with VLANs, and for scaling from a small office to a multi-floor building. Buy it on its own, or let our team handle design, installation, configuration and ongoing management as part of a TTG managed network.
Key Features
- Etherlighting™ ports that illuminate to indicate port location, speed/link, and native VLAN/network*
- (16) 2.5 GbE RJ45 ports
- (32) GbE RJ45 ports
- (4) 10G SFP+ ports
- DC power backup ready
- *Pair with UniFi Etherlighting Patch Cables for optimal brightness.
UniFi Switch Pro Max 48 (USW-PRO-MAX-48) Specifications
| Overview | |
|---|---|
| Dimensions | 442 x 325 x 44 mm (17.4 x 12.8 x 1.7") |
| 1 GbE RJ45 | 32 (1G/100M/10M) |
| 2.5 GbE RJ45 | 16 (2.5G/1G/100M/10M) |
| 10G SFP+ | 4 (10G/1G) |
| Redundancy | DC Power Backup (With UniFi RPS) |
| Form Factor | Rack mount (1U) |
| Performance | |
| Switching Capacity | 224 Gbps |
| Total Non-Blocking Throughput | 112 Gbps |
| Forwarding Rate | 167 Mpps |
| Supported VLANs | 1,000 |
| MAC Address Table Size | 32,000 |
| IPv4 Static Routes | 256 |
| Packet Buffer Size | 2 MB |
| IPv4 | 128 |
| MAC | 128 |
| Hardware | |
| Max. Power Consumption | 100W |
| Power Method | (1) Universal input, 100–240V AC, 50/60 Hz (1) USP RPS DC input |
| Power Input Method | AC input |
| Power Supply | AC/DC, internal, 100W |
| Supported Voltage Range | 100–240V AC |
| Management | Ethernet AR |
| Heat Dissipation | 341.2 BTU/hr |
| Weight | Without mounting brackets: 4.8 kg (10.6 lb) With mounting brackets: 4.9 kg (10.8 lb) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| Supported Rack Depth | 400~1200 mm (15.7-47.2") |
| LCM Display | 1.3" touchscreen |
| ESD Protection | Air: ± 16kV, contact: ± 12kV |
| Ambient Operating Temperature | -5 to 40° C (23 to 104° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC, Anatel: 06373-24-08356 |
| Software | |
| UniFi Network | Version 8.0.24 and later |
Why Buy Ubiquiti from Texas Technology Group?
- Authorized Ubiquiti reseller — genuine products with full US manufacturer warranty.
- Texas-based experts — Houston headquarters serving Corpus Christi, Dallas–Fort Worth, Austin, San Antonio and statewide.
- Design, install & manage — site surveys, cabling, configuration and ongoing managed IT support.
- Business & volume pricing — quotes for multi-site and project deployments.
Frequently Asked Questions
Can TTG install the UniFi Switch Pro Max 48 at my business in Pearland?
Yes. Our technicians install and configure Ubiquiti equipment throughout Texas. Call or text (713) 824-1035 to schedule.
Is the USW-PRO-MAX-48 covered by warranty?
Yes. Texas Technology Group is an authorized Ubiquiti dealer, so every product ships new with the standard Ubiquiti manufacturer warranty. UI Care extended coverage is available for many models.
Do you offer project or volume pricing?
Yes — contact us at (713) 824-1035 for multi-unit, multi-site or full-deployment quotes.
Browse more: Pro Max & Pro XG Switches.
Additional information
| Weight | 13.10 lbs |
|---|
