$328.99
Compact PoE+ switch* with (1) 10 GbE port, (7) 2.5 GbE ports, and 6 GHz-ready WiFi 7 bridging integration for seamless, high-capacity wireless uplink to UniFi WiFi.
- Model: UDB-SWITCH
- Authorized Ubiquiti dealer — full US warranty
- Professional installation available across Texas
- Questions? Call or text (713) 824-1035
Available on backorder
Description
Ubiquiti UniFi Device Bridge Switch (UDB-SWITCH) — Authorized Ubiquiti Dealer in Texas
Compact PoE+ switch* with (1) 10 GbE port, (7) 2.5 GbE ports, and 6 GHz-ready WiFi 7 bridging integration for seamless, high-capacity wireless uplink to UniFi WiFi.
Texas Technology Group has supported businesses in Sugar Land and across Texas since 2002. We recommend the UniFi Device Bridge Switch for seamless roaming between rooms and floors, and for high-density spaces like waiting rooms, classrooms and event venues. Buy it on its own, or let our team handle design, installation, configuration and ongoing management as part of a TTG managed network.
Key Features
- 5 GHz, 6 GHz
- 1 x Internal Antenna(s)
- Internal
- MIMO Technology
- 8 x Network (RJ-45)
- 10 Gigabit Ethernet, 2.5 Gigabit Ethernet
- PoE+ (RJ-45) Ports
UniFi Device Bridge Switch (UDB-SWITCH) Specifications
| Overview | |
|---|---|
| Dimensions | 212.9 x 113 x 32.5 mm (8.4 x 4.4 x 1.3") |
| WiFi Standard | WiFi 7 |
| Spatial Streams | 4 |
| Mounting Locations | Desktop, wall |
| Power Method | DC jack (54V DC/1.1A) |
| Power Supply | 54V DC/1.1A (Adapter included) |
| Performance | |
| 6 GHz | 2 x 2 |
| 5 GHz | 2 x 2 |
| 6 GHz | 5.8 Gbps (BW320) |
| 5 GHz | 4.3 Gbps (BW240) |
| 6 GHz | 8 dBi |
| 5 GHz | 8 dBi |
| 6 GHz | 23 dBm |
| 5 GHz | 26 dBm |
| Max. Conducted TX Power | 26 dBm (Combined) |
| 802.11be (WiFi 7) | 6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/320) 5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/240) |
| 802.11ax (WiFi 6) | 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160) |
| 802.11ac (WiFi 5) | 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160) |
| 802.11n | 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40) |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Wireless Security | WPA3 SAE (Always On) |
| Hardware | |
| Max. Power Consumption | 25W (Excluding PoE output) |
| Supported Voltage Range | 42.5–57V DC |
| Networking Interface | (1) 10 GbE RJ45 port (7) 2.5 GbE RJ45 ports |
| PoE Interface | (8) PoE+ ports |
| Max. PoE Wattage per Port | 30W |
| Total PoE Availability | 60W AC adapter input: 35W 210W AC adapter input: 185W |
| Antennas | (1) Internal |
| Management | Ethernet WiFi |
| Channel Bandwidth | 20/40/80/160/240/320 MHz |
| Weight | Device: 548 g (1.21 lb) With mount: 563 g (1.24 lb) |
| Enclosure Material | Polycarbonate |
| Mount Material | Polycarbonate |
| LCM Display | 0.96" status display |
| Button | (1) Factory reset |
| Certifications | CE, FCC, IC |
| Operating Frequency | Worldwide: 5150—5875 MHz 5945—7125 MHz |
| Ambient Operating Temperature | -30 to 40° C (-22 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Software | |
| UniFi Network | Version 10.0.156 or later. |
Why Buy Ubiquiti from Texas Technology Group?
- Authorized Ubiquiti reseller — genuine products with full US manufacturer warranty.
- Texas-based experts — Houston headquarters serving El Paso, Dallas–Fort Worth, Austin, San Antonio and statewide.
- Design, install & manage — site surveys, cabling, configuration and ongoing managed IT support.
- Business & volume pricing — quotes for multi-site and project deployments.
Frequently Asked Questions
Can TTG install the UniFi Device Bridge Switch at my business in Sugar Land?
Yes. Our technicians install and configure Ubiquiti equipment throughout Texas. Call or text (713) 824-1035 to schedule.
Is the UDB-SWITCH covered by warranty?
Yes. Texas Technology Group is an authorized Ubiquiti dealer, so every product ships new with the standard Ubiquiti manufacturer warranty. UI Care extended coverage is available for many models.
Do you offer project or volume pricing?
Yes — contact us at (713) 824-1035 for multi-unit, multi-site or full-deployment quotes.
Browse more: WiFi Bridging.
Additional information
| Weight | 2.55 lbs |
|---|
